Boom/Stick Option (Hex) 1
Shipping Length Of Unit: 15.75ft in
Max Cutting Height: 15.29ft in
Max Loading Height: 11ft in
Max Vertical Wall Digging Depth: 8.76ft in
Max Digging Depth: 11.03ft in
Boom/Stick Option (Hex) 1: Stick 5’5″ (1650mm)
Length Of Track On Ground: 5.59ft in
Ground Clearance: 0.92ft in
Height To Top Of Cab: 8.21ft in
Tail Swing Radius: 2.86ft in
Engine
Engine Make: 2291
Engine Model: Yanmar 3TNV88-PNS, A TIER II
Net Power: 28.8hp
Power Measured @: 2400rpm
Displacement: 100cu in
Operating Weight: 8002lb
Fuel Capacity: 11.7gal
Hydraulic System Fluid Capacity: 11.9gal
Operating Voltage: 12V
Alternator Supplied Amperage: 71amps
Hydraulic System Relief Valve Pressure: 3481psi
Hydraulic Pump Flow Capacity: 31.2gal/min
