Make: Kubota D1803CRT
Emissions Certification: Tier 4 Final
Type: Diesel
Cylinders: 4
Bore/Stroke: 3.46 x 3.54 in (88 x 90 mm)
Displacement: 134.3 in3 (2.2 L3)
Fuel: #2 Diesel
Cooling: Liquid
Rated engine speeds: 2500 RPM
Horsepower @ rated RPM:
Gross: 43.9 hp (32.8 kW)
Net: 43.5 hp (32.7 kW)
Drive: Hydrostatic
Max. working speed: 3.7 mph (6.0 kph)
Max. travel speed: 6.2 mph (10.0 kph)
Service brake: Hydrostatic
Parking brake: SAHR
Emergency brake: SAHR
Drum drive: Front and rear
Drive pump motors:
Variable displacement: 1
Fixed displacement: 2
Max. relief pressure: 6,454 psi (44.5 MPa)
Gradeability (vibration off): 30% (40%)
Voltage: 12 Volts
Battery: 1 x 12 Volt
Battery reserve capacity: 77 Ah/20 hour
Cold cranking amps: 760 CCA
Insulated from chassis by flexible shock
absorbers; Handrail; Instrument panel;
Anti-vandal guard; Lateral sliding seat; Foldable
ROPS protection; Electronic single lever speed
and direction control with integrated RPM setting,
parking brake, vibration, drum sprinkling, edge
cutting activation (up/down).
